Introduction

As Kubernetes has become the foundational building block for enterprises to go cloud-native, the last couple of years have seen many solutions that have simplified the cluster creation process. But the Day-2 operations around Kubernetes still remains a complex endeavor, slowing down adoption and increasing the operational costs. Kubernetes’ complexity and skills gaps still remain the biggest factors that are in the way of Enterprise’s adoption of Kubernetes.

Many of the Day-2 operations use cases include requirements for the central platform team to deliver secure and compliant environments to developers as efficiently as possible with necessary services and best practices preconfigured. Some examples of such use cases include configuring environments with Kubernetes best practices like resource quotas, network policy and pod security. This requires tools that can assess the environments as they are created and then configure them in compliance with the standard defined by the central platform team.

Kyverno: A Flexible Ops Tool for K8s

Kubernetes provides powerful constructs like admission control webhooks that can be leveraged for the purposes of validating and mutating resources. Nirmata’s Kyverno was designed specifically to address these types of use cases using the declarative paradigm. Kyverno is an open-source policy engine that was designed for Kubernetes, It provides users with familiar constructs to write custom rules and easily implement to validate, mutate, and generate new resources as needed.

Managing Kubernetes at scales requires the following best practices and applying standardization across configurations. One such pattern is to use Kubernetes labels. In Kubernetes, every resource can have one or more labels and Kubernetes makes it easy to find and manage the resources using labels.

A very common use case for Day-2 operations is managing labels across namespaces and pods so that use cases like certificate updates, self-service logging/monitoring, backups etc. can be easily implemented by other Kubernetes controllers and operators.

Auto-Labeling Namespaces

Below is an example of how to implement namespace labeling upon creation in a Kubernetes cluster using Kyverno.

Install Kyverno in your cluster:

kubectl create -f https://github.com/kyverno/kyverno/raw/master/definitions/install.yaml

Detailed installation instructions are available here.

Here is a sample Kyverno policy that adds labels to namespaces  –

apiVersion: kyverno.io/v1
kind: ClusterPolicy
metadata:
  name: add-labels
spec:
  background: false
  rules:
  - name: add-ns-label
    match:
      resources:
        kinds:
        - Namespace
    exclude:
      clusterroles: ["cluster-admin"]
    mutate:
      patchStrategicMerge:
        metadata:
          labels:
            kyverno/user: "{{ request.userInfo.username }}"
            +(kyverno/network): "default"

The policy inserts a label `kyverno/user`with the value of the user making the API request to create the namespace. The policy also inserts a label `kyverno/network`, but only if one is not already specified by the user. This simple policy demonstrates some powerful features in Kyverno like variable substitution and conditional anchors.

Once the policy is configured in your cluster, create a new namespace and verify the labels have been added to the namespace automatically.

Create a new namespace:

kubectl create ns test

View the namespace:

kubectl get ns test -o yaml

This should show a namespace similar to:

apiVersion: v1
kind: Namespace
metadata:
  labels:
    kyverno/network: default
    kyverno/user: docker-for-desktop

Now, what if you want to make sure that users cannot update a specific label?

Kyverno makes that easy to do as well! Here is a policy that prevents the update of the `kyverno/network` label:

apiVersion: kyverno.io/v1
kind: ClusterPolicy
metadata:
  name: protect-label
spec:
  validationFailureAction: enforce
  background: false
  rules:
  - name: block-updates-for-label
    match:
      resources:
        kinds:
           - Namespace
  validate:
    message: Updating label `kyverno/network` is not allowed
    deny:
    - key: "{{ request.operation }}"
      operator: "EQUALS"
      value: UPDATE

Summary

Managing Kubernetes configurations can be complex, and policy engines provide standardization, automated validation, and the ability to mutate and generate configurations.

Kyverno is an open-source policy engine designed for Kubernetes. It has a minimal learning curve and provides tremendous flexibility for Kubernetes administrators to solve Day-2 operations challenges using Kubernetes’ powerful declarative management capabilities and native tools.

Learn what else Kyverno can do at https://kyverno.io.

Discover the benefits of Kyverno here.
Questions? We’ve got answers. Contact us to get started, please.
